T25 / T28 Upgraded Rebuild Kit GARRETT
T25 / T28 Upgraded Rebuild Kit GARRETT
Regular price
£38.00 GBP
Regular price
Sale price
£38.00 GBP
Unit price
per
Upgraded rebuild kit to suit journal bearing T2, T25 and T28 Garrett turbochargers. May also fit Chinese copies.
The standard turbochargers use a 270* thrust bearing which cannot cope with the increased thrust load at higher boost pressures.
This kit includes a 360* thrust bearing and larger collar to displace the increased thrust load which is a must on these turbochargers to ensure reliability at boost levels above 14psi.
The upgraded rebuild kit includes:
- Heavy Duty 360* Thrust Bearing
- Heavy Duty Thrust Washer
- Heavy Duty Journal Bearings (Wide, T28)
- Heavy Duty Journal Bearings (Narrow, T25)
- Turbine Side Heat Treated Piston Ring
- Compressor Side Heat Treated Piston Ring
- Bearing Housing O-Ring
- Front Seal Plate O-Ring
- Aluminium Seal Plate
- Seal Plate Snap Ring
- Turbine Side Heat Shield
- Journal Bearing Retainers
- Bearing Housing To Turbine Housing Retaining Plates
- Thrust Bearing Mounting Bolts
- Shaft Nut
Care Instructions
Care Instructions
Before installation: Engine oil and oil filter must be replaced. Turbo oil-feed line must be removed and thoroughly flushed to ensure there is no debris.
