T25 / T28 Upgraded Rebuild Kit GARRETT
T25 / T28 Upgraded Rebuild Kit GARRETT
Regular price
£38.00 GBP
Regular price
Sale price
£38.00 GBP
Unit price
per
Tax included.
Couldn't load pickup availability
Upgraded rebuild kit to suit journal bearing T2, T25 and T28 Garrett turbochargers. May also fit Chinese copies.
The standard turbochargers use a 270* thrust bearing which cannot cope with the increased thrust load at higher boost pressures.
This kit includes a 360* thrust bearing and larger collar to displace the increased thrust load which is a must on these turbochargers to ensure reliability at boost levels above 14psi.
The upgraded rebuild kit includes:
- Heavy Duty 360* Thrust Bearing
- Heavy Duty Thrust Washer
- Heavy Duty Journal Bearings (Wide, T28)
- Heavy Duty Journal Bearings (Narrow, T25)
- Turbine Side Heat Treated Piston Ring
- Compressor Side Heat Treated Piston Ring
- Bearing Housing O-Ring
- Front Seal Plate O-Ring
- Aluminium Seal Plate
- Seal Plate Snap Ring
- Turbine Side Heat Shield
- Journal Bearing Retainers
- Bearing Housing To Turbine Housing Retaining Plates
- Thrust Bearing Mounting Bolts
- Shaft Nut
Care Instructions
Care Instructions
Before installation: Engine oil and oil filter must be replaced. Turbo oil-feed line must be removed and thoroughly flushed to ensure there is no debris.
